Platform Capability
EVO Max 4T redefines portability with its powerful platform and all weather design.
Weather rating: IP43, water resistant
Max Flight Time: 42 mins
Wind Resistance: 27 mph
Service Ceiling: 23,000 ft
Image Transmission Range: 12.4 miles
No More Blind Spots
EVO Max 4T is the only commercial drone that combines traditional binocular vision systems and millimeter wave radar technology. This allows the EVO Max 4T's onboard Autel Autonomy Engine to perceive objects down to 0.5 inches, eliminating blind spots, and enabling operation in night and/or rainy conditions.
Skylink 3.0
Skylink 3.0 is a system featuring 6 antennas, 4 frequency bands, AES-256 encryption, and optional 4G integration to provide users with the most advanced flight capabilities ever in an EVO.
Anti Jam, Anti Interference
The EVO Max 4T uses advanced flight control modules and algorithms specially designed to counter RFI, EMI, and GPS spoofing. This enables the users to fly confidently near power lines, critical structures, and in complex areas.
A-Mesh 1.0 - The Drone Industry’s First Mesh Networking Tech
The new A-Mesh system enables drone-to-drone autonomous communication, connection, and collaboration.
Strong Anti-interference: The EVO Max 4T can communicate seamlessly with other drones in the vicinity, unlike a traditional chain structure. If a single drone fails or exits unexpectedly, the entire system will independently self-organize and continue to relay critical information.
Beyond Line-of-Sight Applications: With A-Mesh, multiple aircrafts in the vicinity can act as relay points to greatly improve BVLOS operation effectiveness.
Enhanced Range: Communication nodes can be placed statically on hills or poles to provide full coverage to an area, or a swarm of drones can provide mobile communication points to extend the coverage of the entire group.
Full-Fleet Control: Multiple drones can be controlled autonomously by 1 pilot or by a group of pilots simultaneously with or without LTE coverage. The 4T payload integrates wide-angle, zoom, and thermal cameras with a laser rangefinder to meet a wide-range of workflow requirements.
Mission Ready Payload
The 4T payload integrates wide-angle, zoom, and thermal cameras with a laser rangefinder to meet a wide-range of workflow requirements.
Zoom Camera: Supports for 8K 10x optical zoom, and 160x hybrid zoom with clear details on targets up to 1.24 miles away*
Wide Camera: A 50MP camera with the next generation of Moonlight Algorithm 2.0 boosts post processing and allows the pilot to capture crisp, detailed images in low-light environments.
Thermal camera: Equipped with 640x512 high-resolution thermal imaging camera, 30 fps, and 16x digital zoom
Laser Rangefinder: Tap a target to get the coordinates and altitude rapidly from up to 0.75 miles away.
Autel Enterprise Application Platform
The Autel Enterprise App is built from the ground up for industrial applications and features a brand-new interface for simple, efficient operation. Additional features and semi-autonomous modes maximize the EVO Max 4T's mission capability.
Smart Features
3D Map Planning: Plan, create, and execute a 3D waypoint mission plan on a 3D map.
Mission Reproduction: With this feature activated, fly a manual or semi autonomous mission, or string multiple missions together. The EVO Max 4T will automatically record the camera angles and replicate the mission you just flew.
Quick Mission: Temporary quick missions can be created with executing other missions, and multiple sub-missions can be stacked for enhanced flexhibility.
Multiple Mission Types
The Enterprise App provides various autonomous and semi-autonomous mission planning for industries ranging from public safety to utilities.
Waypoint Missions: Users can add waypoints for flexible, non-structured flight paths.
Rectangular Mission: Supports one-click automatic generation of a rectangular flight path.
Polygon Mission: Supports one-click automatic generation of polygon flight areas.
Oblique photography: Automatically plan 5 groups of routes (1 ortho + 4 oblique) according to the flight area set by the user.
Data Security
Privacy protection: Data involving user and aircraft information, including flight logs, locations, and account information can only be physically accessed via the aircraft locally.
Encrypted Data Storage: Supports AES-256 encryption* for photos, videos, and flight logs, are password-protected.
Enhanced Live View
Multi-channel Projection Screen: Supports simultaneous output of RGB, infrared, night vision, and wide-angle images.
AR Scene: Geo-location data and other aircraft location info detected by ADS-B can overlay on real-time map, which is convenient for users to confirm the drone's location and avoid airborne risks.
Autel SDK
The Autel SDK developer platform is open to the world, helping developers and partners reduce software and hardware development costs and jointly create a new industry ecosystem.
Mobile SDK: Open UX SDK (iOS & Android) can directly call up the ready-made interactive interface.
Payload SDK: Unified interface standards support access to third-party mounts such as microphones and gas detectors.
Cloud SDK: Enables remote live broadcast and control of drones and Nests through third-party platforms or web pages.
In The Box:
- Aircraft
- Battery Charger + Power Cable
- Pair of Spare Propellers
- 1 Screwdriver
- Smart Controller V3
- Smart Controller Lanyard
- Smart Controller Cover
- Pair of Spare Joysticks
- RC Charger
- RC Charging Cable
- Data Cable
- Manuals
- Rugged Case
