Complete Workflow
1. Create 3D Drone Modeling for existing surface
- Fly Mavic 3 Enterprise, Anzu Raptor or LiDAR drone.
- Process with Pix4Dmatic/Pix4Dsurvey , Strayos, Carlson PhotoCapture or simliar software to generate a surface.
2. Drill and blast design
- Import surface into O-PitSurface, Carlson BlastOPS, Strayos, or similar
- Design drilling layout
- Export to GNSS or export directly to your drill with IREDES files
3. Mark drill locations using GNSS
- Import drilling layout into Emlid Flow
- Mark the locations with the Emlid Reach RS3
4. Drill and verify boreholes
- Drill boreholes
- Use O-PitDev, Carslon Boretrak, or similar to measure borehole deviations
- Export/sync borehole data to O-PitSurface, BlastOPS, or Strayos
5. Adjust and blast
- QAQC with O-PitApp for explosives control and other KPI collection in the field
- Adjust blasting plan in O-PitSurface, BlastOPS, or Strayos if necessary
- Blast
6. Design vs field data in O-PitAnalytics
O-PitDev Overview
O-PitDev is a revolutionary solution for measuring borehole deviations in quarries and mines. Developed by scientists and researchers who understand the needs of workers on the ground, O-PitDev features cutting-edge technology for faster and more precise measurement readings. Its waterproof and shock-resistant design makes it ideal for non-metal operations, and it is highly efficient for 360º measurements.
- Quick release rope system.
- Led status indicator for easy and fast operation.
- Structure made of AISI 304 stainless steel.
- Ergonomic nose that makes it easy to operate even in the most complex boreholes.
- Temperatures range from -40ºC to 70ºC and 90% of the materials used are recyclable.
A direct connection to the O-PitDev App transmits data over the O-PitCloud, providing immediate borehole information to the engineer responsible for the project.
The O-PitDev comes equipped with Bluetooth 4.2. BLE connectivity that enables
communication with any smartphone equipped with Bluetooth and Android 8.0. or
above.
O-PitDev includes:
- Probe
- Hard Case
- Battery charger
- Extra USB
- O-Rings
- Armband
- 2 Touch pens
- Rope
- Carabiners
- Cleaning Towel
- Grease
- User manual
- 1-year license of the O-PitDev App
- Protection from lost or unrecoverable probe
