Network rover with centimeter accuracy
Pocket-sized and lightweight rover for data collection with centimeter accuracy. Works with network corrections (NTRIP). Comes with the Emlid Flow app.
Easy to set up, no configuration required
Reach RX uses Bluetooth Low Energy (BLE) that allows you to connect and start surveying with your smartphone or tablet in a few seconds. Enable Bluetooth on your iOS or Android device, find your Reach RX in Emlid Flow, add network correction credentials, and collect your first point. No setting to get wrong.
Centimeter accurate results
Reach RX tracks GPS/QZSS, Galileo, Glonass, and Beidou and gets a fix in under 5 seconds even in challenging conditions.
Pocket-sized and lightweight
The weight of Reach RX is just 250 grams. Take it anywhere—it weighs less than a can of soda and fits in any glove compartment or a backpack pocket.
No need for special training
With Reach RX, you can forget about spending time on in-person training and courses. Reach RX is designed to meet the expectations of both experienced professionals and non-surveyors who need to get highly-accurate results. Now anyone on the team can start using RTK.
Compact and rugged
250 grams
172 mm x 51 mm x 39 mm
Weight like a TV remote controller and able to be carried in your pocket.
IP68
RX is waterproof up to 1.5 m depth. All connectors are completely sealed and protected from water and dust with silicone plugs.
-20 to +65 °C (-4 to 149 °F)
We extensively tested Reach RX in conditions that simulate the coldest winters and hottest summers.
Industrial battery
Li-Ion battery
Industrial battery that handles both high and low temperatures well.
16 hours of work
Full day of work for 1 hour of charging. You can charge on-the-go from any USB port and power bank with the cable that comes with Reach RX.
2000+ cycles
of charging and discharging while maintaining original capacity.
Emlid Reach RX GNSS Specs
GPS/QZSS L1C/A, L2C,
GLONASS L1OF, L2OF,
BeiDou B1I, B2I,
Galileo E1-B/C, E5b
