The EVO Max series brings you advanced autonomy. It assesses complex environments to create real-time 3D flight paths for unparalleled obstacle avoidance. Advanced sensors make flight in GPS unavailable areas possible and the incredible thermal and starlight cameras unlock new object identification and tracking scenarios. With a foldable, weather-resistant design, the series is as portable as it is capable.

  • Starlight Night-Vision Camera | as low as 0.0001 LUX and ISO ranges from 100-450,000
  • Lock Targets & Track at Night
  • Autel SkyLink 3.0 | 12.4 miles Transmission Range
  • 720° Obstacle Avoidance
  • A-Mesh 1.0 | Mesh Networking Technology
  • 3D Map Planning | Multiple Mission Types | Data Security
  • Navigation in GPS Denied Environments
  • 42 mins Max Flight Time
  • IP43 ingress protection, and -20° F～122° F temperature operation range

Aircraft Specifications

Weight 3.62 lbs (1640g, battery and gimbal included)
Max. Takeoff Weight 4.41 lbs (1890 g)
Dimensions 576*660*149 mm(fold, incl. propellers)
340*407*148 mm(fold, excl. propellers)
257*136*133 mm (unfold, excl. propellers)
Diagonal Wheelbase 464mm
Max Ascent Speed 8m/s
Max Descent Speed 6m/s
Max Horizontal Speed (windless near sea level) 23m/s
Maximum Takeoff Altitude 13,124 ft (4000m)
Max Flight Time (windless) 42 mins
Max Hover Time (windless) 38 mins
Max Wind Resistance 27mph*
*Takeoff and landing can withstand wind speeds up to 27 mph (12 m/s).
IP Rating IP43
Max Tilt Angle 35°
Max Angular Velocity Pitch: 300°/s; Yaw: 120°/s
Operating Temperature -20℃～+50℃
Operating Frequency 2.4G/5.2G*/5.8G/900MHz*
*5.2GHz is only applicable for FCC, CE, and UKCA regions. 900MHz is only applicable for FCC regions.
GNSS GPS+Galileo+BeiDou+GLONASS
Transmitter Power (EIRP) 2.4GHz: <33dBm（FCC）, <20dBm(CE/SRRC/MIC)
5.8GHz: <33dBm(FCC), <30dBm(SRRC), <14dBm(CE)
5.15-5.25GHz: < 23dBm(FCC/SRRC/MIC)
5.25-5.35GHz: <30dBm(FCC), <23dBm(SRRC/MIC)
Hovering Accuracy Vertical:
±0.1 m (Vision System enabled);
±0.5 m (GNSS enabled);
±0.15 m (RTK enabled);
Horizontal:
±0.3 m (Vision System enabled);
±0.5 m (GNSS enabled);
±0.1 m（RTK enabled）

Sensor Effective Pixels:2.3M
Lens Focal length: 35mm (equivalent: 41.4mm)
Zoom Range:1-8x(synced zoom supported)
Exposure Compensation ±3EV 0.3EV/step
ISO Range Auto:IOS100-ISO450000
Super Sensitive Mode:Auto IOS100-ISO450000
Electronic Shutter Speed Photo: 8s ~ 1/8000
Video: 1s ~ 1/8000
Max Photo Size 8000×6000
Max. Video Resolution 7680×4320

Wide Camera

Sensor 1/1.28 CMOS, Effective pixels: 50M, Night mode: 12.50M
Lens DFOV：85°
Focal length: 7 mm (equivalent: 23 mm)
Aperture: f/1.9
AF motor: 8-wire SMA, PDAF focus
Exposure Compensation ±3EV 0.3EV/step
ISO Range Auto:
Photo: ISO100~ISO6400
Video: ISO100~ISO64000 (Night mode: up to ISO64000)
Manual:
Photo: ISO100~ISO12800
Video: ISO100~ISO6400
Electronic Shutter Speed Photo: 8s ~ 1/8000
Video: 1s ~ 1/8000
Max. Video Resolution 3840×2160
Photo Size 8192*6144
4096*3072

Thermal Camera

Thermal Imager Uncooled VOx Microbolometer
Lens DFOV: 61°
Aperture: 9.1mm
Focus: f/1.0
Infrared Temperature Measurement
Accuracy		 26.6~37.4 ℉ or reading ±3% (using
the larger value) @ambient
temperature -4℉ to 140℉
Video Resolution 640*512
Photo Size 640*512
Pixel Pitch 12 um
Temperature Measurement Method Center measurement, pot measurement, Rectangular measurement
Temperature Measurement Range -4℉ to 302℉, 32℉ to 1022℉ (-20°C to
150°C, 0 to 550°C)
Temperature Alert High and low temperature alarm thresholds, reporting coordinates and temperature values
Palette White Hot/Black Hot/Searing/Rainbow/Grey/Ironbow/Cold and Hot
